Product Name:
Seven in one air box.
Product size:
87 × 87 × 67mm (power supply).
87 × 87 × 48mm (adapter).
Power supply mode:
directly plugged into AC100-240V50/60HZ.
Adapter DC5V/1A.
Product material:
flame retardant PC.
Installation method:
side mounting / horizontal placement.
Communication method:
ZigBee.
Communication distance:
80mur120m (empty and unsheltered).
Working temperature:
-10-50 ℃.
The measuring range of temperature sensor:
-10 ℃ to 50 ℃, and the typical error is ±1 ℃.
Humidity sensor measuring range:
10~95% RH, typical error ±5%.
Measurement range of light sensor:
0-2000lux.
The output range of the dust particle sensor:
0mm 500ug / m 3, with an error of 20%.
Co2 sensor output range:
0ppm 5000ppm, accuracy ±(50ppm 5% reading).
Formaldehyde sensor output range:
0~2ppm.
Measurement range of noise sensor:
40db-80dB.
Product Name:
Four-in-one air box(PM2.5).
Product size:
87 × 87 × 48mm.
Power supply mode:
Adapter DC5V/1A.
Product material:
flame retardant PC.
Installation method:
side mounting / horizontal placement.
Communication method:
ZigBee.
Communication distance:
80mur120m (empty and unsheltered).
Working temperature:
-10 ℃-50 ℃.
The measuring range of temperature sensor:
-10 ℃ to 50 ℃, and the typical error is ±1 ℃.
Humidity sensor measuring range:
10~95% RH, typical error ±5%.
Measurement range of light sensor:
0-2000lux.
The output range of the dust particle sensor:
0mm 500ug / m 3, with an error of 20%.
