American Standard Intelligent switch Series

Do as one wishes   Light up life

Wonderful life   Be triggered at any moment

american-standard-products

A slight press  Control smart home

anytime, anywhere

Go out in a hurry, one button to solve the trouble of forgetting to turn off the lights

Turn off the lights at night, remote control, reduce noise, care for family sleep

......

american-standard-products

The lighting of the whole house is under control

Changing the traditional single lighting control mode, the multicast function can turn on / off the load lights of different equipment at the same time, and realize the unified management of lamps and lanterns, which is mostly used in apartments and villas

american-standard-products

Outfit both horizontally and vertically

Meet your home improvement environment

According to the needs of the actual situation, you can choose to install the thermostat horizontally or vertically

Connect to different air conditioning facilities (cooling, heating (electric auxiliary heating, oil and gas plumbing), fans)

american-standard-products

LCD liquid crystal scene

Local control / remote control / scene linkage

Switch custom scene mode with one click

......

american-standard-products

Night state

Transparent blue backlight  Softer  Not dazzling

The lights are not afraid of the dark at night

The soft backlight is not dazzling

Soft backlight, quick response, light up the intelligent life. The brightness of the backlight can be adjusted through app

And people who sleep lightly will not have to worry about it

american-standard-products

Free couplet with random collocation

Zero fire switch, dimming switch, four-key scene, intelligent metering socket splicing combination installation

american-standard-products

Seiko quality  Multiple protection

VO fire grade material, multi-layer structure technology, flame retardant, corrosion and impact, safety, energy saving and intimate protection

Product Name: Zero fire switch.
Flame retardant grade: V-0.
Product size: 74mm*119mm*53.8mm.
Rated voltage: AC120V ± 10% 50 / 60HZ.
Working temperature: -10 ℃ ~ 40 ℃.
Working humidity: < 95%RH (does not condense).
Communication method: IEEE802.15.4 (Zigbee).
Communication distance: 100m (open).
Load: resistive load ≤ 1800W.
Connection method: lead wire.
Product Name: Four-button scene panel.
Flame retardant grade: V-0.
Product size: 74mm*119mm*53.8mm.
Rated voltage: AC120V ± 10% 50 / 60HZ.
Working temperature: -10 ℃ ~ 40 ℃.
Working humidity: < 95%RH (does not condense).
Communication method: IEEE802.15.4 (Zigbee).
Communication distance: 100m (open).
Connection method: lead wire.
Product Name: Dimming switch.
Model: C4220100.
Rated voltage: 120 V a.c. 50/60 Hz.
Load: 600 W (Incandescent/Halogen/Resistive) 150 W (LED/CFL).
Minimum load: 10W.
Operation temperature: -10℃~40℃/14-104℉.
Operation humidity: <95% RH.
Installation environment: Indoor use only.
Communication mode: ZigBee.
Protection level: Type 1 enclosure & IP20.
Relay Type: 1.B action.
Pollution degree: 2.
Rated impulse voltage: 2500V.
Download: Instructions
Product Name: Intelligent metering socket.
Flame retardant grade: V-0.
Product size: 74mm*119mm*53.8mm.
Rated voltage: AC120V ± 10% 50 / 60HZ.
Working temperature: -10 ℃ ~ 40 ℃.
Working humidity: < 95%RH (does not condense).
Communication method: IEEE802.15.4 (Zigbee).
Communication distance: 100m (open).
Load: resistive load ≤ 1800W.
Measurement accuracy: 1%.
Metering channel: independent 2 channels.
Connection method: lead wire.
Product Name: Intelligent thermostat.
Flame retardant grade: V-0.
Product size: 103.28*119.33*46mm.
Power supply: 24AC (50hz/60hz). Maximum 1A (single output). Maximum 3A (all output). Peak 5A.
Working temperature: -10 ℃ ~ 40 ℃.
Working humidity: < 95%RH (does not condense).
Communication method: IEEE802.15.4 (Zigbee).
Communication distance: 100m (open).
Connection method: lead wire.
Product Name: LCD liquid crystal scene.
Flame retardant grade: V-0.
Product size: 103.28*119.3346mm.
Rated voltage: AC120V ± 10% 50 / 60HZ.
Working temperature: -10 ℃ ~ 40 ℃.
Working humidity: < 95%RH (does not condense).
Communication method: IEEE802.15.4 (Zigbee).
Communication distance: 100m (open).
Connection method: lead wire.

* the above data are from UIOT laboratory, and the actual results may vary slightly depending on the test method.
