Internet of things curtain motor

The innovative work of the industry, the forerunner of high-end intelligent curtains

One-button opening and closing / magnesium-aluminum alloy integrated molding / strong torque of imported motor

iot-curtain-motor

Integrated forming of magnesium and aluminum alloy

The fuselage is made of magnesium-aluminum alloy, which has gone through many processing procedures and has been fresh for a long time

iot-curtain-motor

Strong signal coverage

Break through the mainstream configuration

New ZigBee solution covering up to 100m

iot-curtain-motor

Curtain fabric rebound

When the curtain is opened to the maximum extent, the electricity will bounce back automatically

Avoid squeezing the curtains, which can prolong the service life of the curtains

It does not affect the sag of the curtains

iot-curtain-motor

Light pull start   Safe and considerate

With a slight pull, the curtains can be opened and closed automatically

Intelligently predict your action trend to meet the needs of the elderly, children and other users

iot-curtain-motor

Extreme weather  Deal with it well

Cooperate with UIOT Super Wise Home window opener in cloudy and rainy weather, automatically close window curtains

Considerate service to create a new generation of super wise experts

iot-curtain-motor

Small stature and big energy

Imported strong torque motor, no matter how thick the curtains are, they can be pulled easily

Super mute gear, enjoy a comfortable life

Product Name: Intelligent curtain motor.
Product color: silver gray.
Product material: aluminum alloy.
Installation mode: Wall fixed frame installation.
Product size: 260 × 52 × 80mm.
Operating voltage: AC100-240V 50/60HZ.
Communication method: ZigBee.
Communication distance: 80mur120m (empty and unsheltered).
Working temperature: -10 ℃ ~ 50 ℃.
Rated power: 30W.
Maximum load: 50KG.
Control mode: hand start / strong power control / weak power control / RF remote control / APP.
Rated torque: 1.5N m.
Opening and closing speed: 10 cm/s, 12 pm, 14 pm, 17 pm (adjustable).
Protection level: IP41.
Product Name: Intelligent opening and closing curtain motor PRO style.
Product color: White.
Product material: aluminum alloy.
Installation mode: Wall fixed frame installation.
Product size: 310 × 68 × 50mm.
Operating voltage: AC100-240V 50/60HZ.
Communication method: ZigBee.
Communication distance: 80mur120m (empty and unsheltered).
Working temperature: -10 ℃ ~ 50 ℃.
Rated torque: 1.5N m.
Opening and closing speed: 12cm/s (adjustable).
Protection level: IP20.
Control mode: RF remote control / APP (Zigbee).

* the above data are from UIOT laboratory, and the actual results may vary slightly depending on the test method.
