touch_pro_series

Touch PRO

Light up at the touch of a world

touch_pro_series

Intelligent single / two-way curtain control panel

Arbitrary control to realize intelligent opening with one button

touch_pro_series

2.5D drip screen

Iphone manufacturing process

More visual tension without overflow

Product name: Zero fire switch.
Product size: 86 × 86 × 36mm.
Rated voltage: AC100-240V 50/60Hz.
Working temperature: -10 ℃ ~ 50 ℃.
Communication method: ZigBee.
Communication distance: 80-120m (empty and unsheltered).
Single load: resistance ≤ 800W; inductance and capacitance ≤ 400W
Product name: LCD scene panel.
Product size: 86 × 86 × 36mm.
Rated voltage: AC100-240V 50/60Hz.
Working temperature: -10 ℃ ~ 50 ℃.
Communication method: ZigBee.
Communication distance: 80-120m (empty and unsheltered).
Product name: Four-button scene panel.
Product size: 86 × 86 × 36mm.
Rated voltage: AC100-240V 50/60Hz.
Working temperature: -10 ℃ ~ 50 ℃.
Communication method: ZigBee.
Communication distance: 80-120m (empty and unsheltered).
Product name: Motor control panel.
Product size: 86 × 86 × 36mm.
Rated voltage: AC100-240V 50/60Hz.
Working temperature: -10 ℃ ~ 50 ℃.
Communication method: ZigBee.
Communication distance: 80-120m (empty and unsheltered).
Single load: ≤ 200W

* the above data are from UIOT laboratory, and the actual results may vary slightly depending on the test method.
